SM30301 2MP Hand USB Microscope



To equip 2.0MP sensor and offers full screen display at 25 inch screen. In compare with MDA1300, MDA2000 has bigger image file to capture, but lower frame rate, so MDA2000 is more suitable for capturing images of still object or slow move target for close look.



Features

Low magnification
1X---40X
High magnification
200X
Working distance
5.00 mm---∞
Lighting source
8 LED light ring
Focusing
Hand-wheel and twin screw track
Function of software
Image management: to set up, to open up, to save, and to lead in image file
Image capture: to switch, to set, to shoot, to video.
Image edit: picture turn, zoom, cut, modify, email, print
Resolution of display
1600*1200
Resolution of picture
1600*1200
Resolution of video
1600*1200
USB cable
1.5 m
Weight of device
0.12kg



Specification：

Sensor parameter
1/3.2” 2.0 Mega Pixels CMOS
Active Pixels
1600*1200
USB port
USB 2.0
Frame Rate
7.5 f/s @ 1600*1200
Preview Model
1600*1200,1280*1024,640*480, 320*240，
Dynamic Range
68dB
Sensitivity
1.0V/lux-sec@550nm
Spectrum response
400nm---1000nm
Shutter Type
ERS(electronic rolling shutter)
White Balance
Auto
Operating System
Windows XP, Vista


Packing message:
1. Single box：Weight: 0.211kg，Measurement: 3.65*3.65*5.0 cu cm
2. One carton of 40PCS: Weight: 9.10 kg, Measurement: 57.0*30.0*28.0cu cm
