SM30400 XY series biological microscope
■ 40x,100x objective with spring for protecting itself and preparate.
■ Eyepiece holder,focus machanism and stage is made from splendid metal alloy.
■ Handiness press style clip.
■ Focus machanism with adjustable limited device and damping device.
■ Handy and safe wooden box packing.
Specifications
|
Objective
|
Achromatic objectives 4X、10X、40X(S)
|
|
Eyepiece
|
Huygens H5X、H6X、H10X、H12.5X、H15X、H16X,widefield WF10x/18mm eyepiece
|
|
Focusing Adjustment
|
Vertical monocular head,coarse focusing adjustment range 21mm
|
|
Enlargment Ratio
|
20X-640X
|
|
Illuminator
|
φ42mm plano-concave mirror and fork
|
|
Nosepiece options
|
Single adapter
|
|
Triple adapter
|
|
|
Stage
|
88x84mm Plan stage
|
|
Diaphragm
|
Rotary disc diaphragm
|
|
Condenser
|
N.A.0.65 fixed condenser
|
|
